DC10 Electric 1/10 2WD Drift Car Kit
Couldn't load pickup availability
Required to Complete:
- 1:10 scale 540-size electric motor (#27481 Sonic 540-SP5 13.5T Brushless Motor)
- 1:10 scale electronic speed control (#27016 Blackbox 610R Competition ESC)
- 7.4V-7.6V 2S LiPo with "shorty" battery dimensions (standard or low-profile height) (#27397 Reedy Zappers SG5 LiPo 4000mAh 130C 7.6V LP Shorty)
- Drift Steering Gyro
- Radio control battery charger (#27203 Reedy 1416-C2L Dual AC/DC Competition Balance Charger)
- 2-channel RC car surface transmitter and its batteries
- 2-channel receiver
- Steering servo (#27154 Reedy RS1606A Low-Profile Hi-Speed HV Servo)
- Pinion gear (48 pitch)
- Spray paint for Lexan body
- 1:10 scale wheels and tires
- Other helpful items: Silicone Shock Fluid, Silicone Diff Fluid, Body Scissors (#1737), Reamer / Hole Punch, FT Wrench Set (#1519), Hobby Knife, Needle Nose Pliers, Wire Cutters, Soldering Iron, Calipers or a Precision Ruler
Features:
- Factory Team hard-anodized threaded aluminum shocks
- Factory Team 2.5mm carbon-fiber drift chassis
- Factory Team 2.5mm carbon-fiber shock towers
- Two Factory Team 2.5mm carbon-fiber top plate options included
- Factory Team blue-anodized aluminum chassis post
- High and low motor mounting options
- +6mm transmission height adjustment insert allows for higher roll center and larger spur gear
- Maximum steering throw for optimal control drifting through turns
- Easy-to-tune caster adjustments can be made without tools
- Adjustable battery placement
- Fully tunable, blue-anodized aluminum Ackermann plates
- Easy-to-adjust camber
- Adjustable offset wheels hexes
- Adjustable servo mount locations
- Precision rubber-sealed ball bearings throughout
- Rear mounted electronic speed control (ESC) plate
- Adjustable rear anti-squat and toe-in
Specifications:
- Scale: 1:10
- Power: Electric
- Front Width: 172mm (6.7")
- Rear Width: 180mm (7")
- Wheelbase: 257mm (10.1")
- Transmission Ratio: 2.6:1
- Drivetrain: RWD/2WD
- Environment: Drift Track
